 F-Cloud Foxeer XAT520 520TVL CMOS Camera QAV250210 Crossing FPV Model Camera For Racing drone High quality

Included:
1 x Foxeer XAT520 camera

This light weight (4.5g) 520TVL CMOS camera is an excellent addition to your FPV gear. Its size allows it to be used for the smallest of drones but can used in any frame or plane. Minimum illumination of 0.008 Lux for excellent low light performance when flying through shadows or on darker days.

Note: This camera is also avialable in PAL format.

Features:
• 520TVL CMOS
• 0.008 Lux / F1.2
• FOV 100 deg
• Small size and lightweight

Specs:
Sensor: Single Chip ¼ CMOS
System: NTSC
Number of Pixels: 656 x 492
Image Signal Process: Digital Signal Processing System
Sensor Dimension: 4.75 x 3.55mm
Horizontal Resolution: Approx 520TVL
Scanning System: 2:1 Interlace
Sensitivity: 0.008Lux/F1.2
Lens / View Angle: F2.0 / 100deg
S/N Ratio: 52dB
Electronic Shutter: Auto (1/60s to 1/100000s)
Auto Gain Control: Auto
White Balance Control: Auto
Back Light Compensation: Auto
Video Out: 1.0V p-p / 75ohm
Work Current: 60mA
Power Requirement: 5-24V DC
Operating Temperature: -10C~+50C, less than 90% RH
Dimensions: 11.8 x 11.8 x 24.5mm
Weight: 4.7g (with cable)

 '
