FMUSER FMT-600W 500W 600watts FM Transmitter + RDS Encoder for Radio Broadcasting Station |

FMUSER FMT-600W 500W 600watts FM Transmitter + RDS Encoder for Radio Broadcasting Station |

This link to sell the FM Transmitter and RDS encodet Kit. You can use the transmitter with a logo of your Radio showing on the car or other radio station. Like the picture:

Now Buy FSN5 Series Transmitter, You will get a 50% discount on FMUSER RDS-A Encoder.
The FMUSER RDS-A encoder official price is 600USD, and the 50% discount price is 300USD(It is only applicable if purchase one FSN
series transmitter and get a RDS-A encoder 50% discount).

There is no better time than now, BUY IT NOW

Frequency Question (FAQ)

2. Traffic Program (TP):

RF Part:
Frequency: 87.5-108MHz,
Frequency step value: 10KHz
Modulation: FM, peak deviation ± 75KHz
Frequency stability: <± 100Hz
Frequency stabilization method: PLL frequency synthesizer
RF output power: 0~600 watts ± 0.5dB
Residual wave: <- 70dB
Higher harmonics: <- 65dB
Parasitic AM: <- 50dB
RF output impedance: 50Ω
RF output connector: L29 female

Audio Part:
Audio input connector: XLR female
AUX input connector: BNC female
Pre-emphasis: 0us, 50us, 75us (user setting)
S / N ratio mono:> 70 dB (20 to 20KHz)
S / N ratio stereo:> 65 dB (20 to 15KHz)
Stereo resolution: -50dB
Audio frequency response: 30 ~ 15000Hz
Audio distortion: <0.3%
Audio level gain: -12dB ~ 12dB step 3dB
Audio input: -19dB ~ 5dB

General Features:
Power supply voltage range: 110V ~ 260V
Operating temperature range: -10 to 45 ℃
Work mode: continuous work
Cooling method: air cooling
Cooling efficiency: <95%
Work Altitude: <4500M
Power consumption: 1500VA
Dimensions: 483 x 320 x 88 mm without handles and protrusions, 19 "2U standard rack.
Weight: 15Kg

Overview

FMUSER RDS-A Encoder is well suited for most regional, local, RSL, LPFM and
other medium- and small-coverage radio stations which use Ethernet for dynamic
RDS data distribution. Built-in Ethernet controller supports multiple TCP/UDP
ports, internet functions and remote monitoring .

FMUSER RDS-A Encoder have Fully DSP concept and effective design ensures
high reliability, excellent signal characteristics and gives the user many
advanced features while maintaining low acquisition costs.

Features

lFully dynamic FM broadcast RDS encoder with up to four independent
communication ports

lUSB connectivity for local settings and maintenance purposes

lEthernet connectivity for linking with broadcast automation system

lControl interface based on ASCII commands and UECP protocol

lSupports internet functions and remote monitoring

lText features include dynamic PS, parsing, scrolling, tagging, fixed
messages, scheduling and HTTP reading

lExcellent compatibility with broadcast automation systems

lControl software includes powerful Windows GUI application

lSupports control from external PHP/ASP scripts

lEasy and fast set-up

lExcellent spectral purity, direct digital RDS signal synthesis; compliant
with EN 50067 / EN 62106

lTwo switchable program sets (with optional DSN and PSN setting)

lExternal TA and Program set switch

lBypass relay, high reliability

lSwitchable MPX loopthrough mode (Loop/Side)

lInternal real-time clock incl. backup battery

lNo special 19 kHz input needed - pilot tone internally recovered from MPX
signal using digital PLL

Package include:

1* FM Transmitter 600W

1* RDS Encoder
