2pcs Dia 20/25/30mm Round Neodymium Magnets Thick 3/4/5/10mm With M5 M6 Countersunk Hole Strong Permanent Rare Earth Magnet |

2pcs Dia 20/25/30mm Round Neodymium Magnets Thick 3/4/5/10mm With M5 M6 Countersunk Hole Strong Permanent Rare Earth Magnet |

Magnets are special items with limited logistics channels. If you have special requirements, please contact us.

Description:

Shape: Round

Material: NdFeB

Grade: N35

Diameter: 20mm 25mm 30mm

Thickness: 3mm 4mm 5mm 10mm

Hole: 5mm 6mm

Max Working Temperature: 80°C

Tolerance: ± 0.3~0.5mm

Plating: Nickel + Copper + Nickel Triple Layer Plated

Magnetic Pole Direction: Axially magnetized / Poles on flat ends

A neodymium magnet, also known as NdFeB, is the most common type of rare earth magnet.

Notice:

1. Strong magnets have the property of being hard and brittle. They are fragile products. Don't collide or fall! When separating the magnet, be sure to move it offset and not separate it directly to avoid damaging the magnet. After disconnecting, you should keep a certain distance to avoid sudden magnetism, which will lead to strong collisions and damage the magnet.

2. The magnets are industrial products, all of which are measured manually and can have a tolerance of ± 0.3 mm. Thank you for your understanding.

3: Strong magnets should keep away from ironware and some easily magnetized iron products, such as monitors, bank cards, computers, televisions and mobile phones

4:Prohibit contact and use by children under 8 years old, prevent children from swallowing

Applications:

Acoustic field: the speaker, receiver, microphone, alarm, stage audio, car audio and so on.

Electronics: permanent magnetic actuator vacuum circuit breakers, magnetic relays, meter, meter, sound meter, a reed switch, sensors.

Electrical field: VCM, CD / DVD-ROM, generators, motors, servo motors, micro-motors, motors, vibration motors.

Machinery and equipment: magnetic separation, magnetic crane, magnetic machinery.

Healthcare: MRI scanners, medical equipment, magnetic health products and so on.

Other industries: magnetized Wax, pipe descaling, magnetic fixture, automatic mahjong machine, magnetic locks, doors and window magnetic, magnetic luggage, leather magnetic toys, magnetic tools, gifts and packaging.

Package included: According to your choice
