1, BMW 5er F10 CAS4Remove the CAS from the car in the driver’s side

Figure 1

Open the case, and remove the unit in the red circle.

Figure 2

Figure 3

Connect the wires as the figures shown:

Figure 4

Done shown as followed figure 5.

Figure 5

2, BMW 1 Series F20/3 Series F30 Back of dash shown as figure 6

Figure 6

Remove the component labeled, and connect the points with the same color on BMW canblocker to the dash. Shown as figure7:

Figure 7

Install BMW can blocker to the dash successfully.

2, BMW 1 Series F20/3 Series F30 Back of dash shown as figure 8

Figure 8

Connect the points with the same color on BMW can blocker to the dash. Shown as figure 9:

Figure 9

Install BMW can blocker to the dash successfully.

4、BMW 5 Series F10/7 Series F01 Back of dash shown as figure 10.

Figure 10

Remove the component in red circle in figure 10:

Figure 11

Connect the points with the same color on BMW can blocker to the dash. Shown as figure 12:

Figure 12

Install BMW can blocker to the dash successfully.
