100nodes DC12V WS2811 LED C9 type pixelwaterproof full color with faceted White coverwith transparent wire | Освещение

100nodes DC12V WS2811 LED C9 type pixelwaterproof full color with faceted White coverwith transparent wire | Освещение

Features:

1. Adpots high quality 8mm 0.24w round hat RGB LED as lighting source.

2. With good proection level. can achieve IP68.

3. each module as one pixel, takes 3 dmx channels,white strobe color,can be controlled individually,

4. It is easy installation, open hole.

5;good waterproof type,IP68 rated,epoxy resin filled

6;using the strong cabe,with good cold resistance ability

7:works with dmx matrix controller,or SPI pixel controll,on-line controller.etc

Specification:

Part No

RA-2811-12V-C9-T

Color

full rgb color,24bit,256 gray scale

LED Qty

1pcs 8mm round hat 0.24w rgb led with 4pin common anode

Input Volt

DC12V

Max current

200MA

Max Power

0.24W

Driver method

Constant current circuit

Dimension

L32mm*W18mm*24mm

Viewing angle

100-120degree

Protection Level

IP66

Certification

CE and RoHS

Standard connection

100pcs module per string

Standard wire length

100mm(from side to side of the pixel)

Housing

transparent PVC

Fixed way

open hole

Lifespan

35000 hours

Warranty

3years

Operation temperature

-40-50

Store temperature

-50-60

Applications:

lights, back lights, cabinet lights, edge light, architectural lights for corridor, canopy, archway, lights for path
and contour marking; etc.
They can be a good choice for advertising,Led screen, night clubs, coffee / wine bars, shopping malls,
various shops, cinemas, beauty centers, office fronts, even lights for household kitchens or living rooms, etc.
