SMTSEC 1/2.8" Sony CMOS 2.0MP 3x Optical 12x digital zoom 3.27 Megapixel USB3.0 HD Video Conference Camera(SCV-HD610-U30-SE600) |

SMTSEC 1/2.8" Sony CMOS 2.0MP 3x Optical 12x digital zoom 3.27 Megapixel USB3.0 HD Video Conference Camera(SCV-HD610-U30-SE600) |

SMTSEC 1/2.8" Sony CMOS 2.0MP 3x  Optical 12x digital zoom 3.27 Megapixel USB3.0 HD Video Conference Camera(SCV-HD610-U30-SE600)

Low Cost High Performance 2.0 M HD Video camera achieved 1080p@30 high quality images. Equipped with SONY 3x optical, 12x digital zoom lens with wide Horizontal View field, ideally for small-sized videoconference rooms, auditoriums, and classroom. Support USB Interface which is easy to installation and transfer high-quality video streaming.

Features:

 cutting-edge High Definition PTZ camera

 Fast and smooth video handling

 Low cost design for marketing

 Power ON-OFF switch

 Work & Standby LED indicator

 Speed Match

 Auto/Manual focus/brightness/WB

 RS-232C/VISCA Protocol

 Lens/Dome OSD

 Boundary scanning

 Standby & wakeup status

 Standard UVC protocol

Performance:

 1/2.8" Type CMOS

 2.0 Megapixel

 0.25 Lux at F1.2

 720P@30, 1080P@30

 3x Optical x 12 digital zoom

 f=3.00 to 9mm F1.2-2.1

 HOV 1080P 90degree,720P 70degree

 USB3.0 Video output

 Pan : 0-355°

 Tilt: Up: 45°, Down: 45°

 64 preset positions

 4 cruise lines

 DC 12V, 2A

Dimension:

 L 250mm x W 140mm x H154mm

 N. Weight: 1.23 kgs (only camera)

 G. Weight: 2.4 kgs (one unit)

 N.W Carton of 2 units: 2.6 kgs

 G. W Carton of 2 units:5.5 kgs

Installation:

 Desktop

 Ceiling mount

 Standard Tripod accessory

Model No.

SVC-HD610-U30-SE600

Sensor

Image Sensor

1/2.8" Type CMOS

Effective Pix

2.0 Megapixel

Min. Illumination

0.25 Lux at F1.2

White balance

Auto/Manual/Indoor/Outdoor

Gain control

Auto

Backlight compensation

On/Off

Shutter speed

1/1~1/10,000S, 22 steps

S/N ratio

>50db

Lens

Focus

f=3.00(wide) to 9mm(tele) F1.2-2.2

Iris

Auto/Manual

Lens

3 Optical x 12 digital zoom

Horizontal view angle

1080P:90 degree

720P:70 degree

Video output

USB3.0

Signal system

720P@30, 1080P@30

Control terminal

EIA/RS232C,EIA/RS485(Bidirectional)

Control Protocol

VISCA,PELCO-D

baud rate

9600/38400bps

patrol line

4 cruise sequence

preset position

64 preset positions

Speed Match

Pan/Tilt movement speed depends on camera module zoom in/out

OSD Menu

Access to OSD Menu and adjust camera module parameters

Image auto flp

Support Horizontal/Vertical image flip

Pan movement speed

1-200°/Second

Tilt movement speed

1-150°/Second

Pan movement range

Pan: 0-355°

Tilt movement range

Up: 45°, Down: 45°

Pan scanning automatically

Support Pan scanning automatically

Boundary scanning

0-359°  scanning (programmable)

Remote controller

IR Wireless Remote controller P/T/Z

Power supply

DC12V,2A

Work Temperature

0-50degree

Humidity

0-95%RH

LxWxH

250mm x 140mm x 145mm

Weight

2.8 kgs
