Using principle of a strong line of controlled light scattering, can get the particle concentration between 0.3 to 10um in the air. It with digital output and built-in fan is stable and reliable.

Features:
Accurate and reliable: Advanced technique detection, stable, good consistency.
Quick response: Response time is less than 10 seconds when the scene changes.
Easy integration: UART output (or IO output can be customized), fan built-in.
High resolution: Resolution of 0.3ug/m3.
Scope of application: PM2.5 Detector, purifier, air exchangers, filtering system.

Specifications:
Measuring Output: PM2.5, PM10
Range: 0.0-999.9 ug/m3
Power Supply Voltage: 5V
MAX Working Current: 100mA
Sleep Current: 2mA
Operating Temperature Range: -20 - 50℃
Response Time: 1s
Serial Data Output Frequency: 1 time/s
Particle Diameter Resolution: less than 0.3um
Relative Error: 10%
Item Size: 71 * 70 * 23mm / 2.80 * 2.76 * 0.91in
Package Size: 100 * 100 * 50mm / 3.94 * 3.94 * 1.97in
Package Weight: 100g / 3.53ounce

Package List:
1 * Sensor
