Wireless Bluetooth Gamepad For Nintendo Switch Console NS Game Controller Gamepads For NFC/Turbo/Auto Turbo Som S7

1. Mode and connection description:
Switch mode: press Y+Home for 2 seconds to enter the Bluetooth search mode, LED1-LED4 flashes, the corresponding channel indicator is always on (Switch host assignment); synchronization status, or is being paired with the host: LED1-LED4 horse flashing ;
Note: After the controller enters the sync mode, it will automatically sleep if there is no synchronization within 2.5 minutes.
Android mode: Press A+Home for 2 seconds to enter the Bluetooth search mode. The LED is LED2/LED3. When pairing, the LED flashes quickly and the connection is successful.
2. Connect mode:
Press the Home button for 1 second to wake up the handle. After being woken up, it will automatically connect to the host that is paired with it. If the connection is unsuccessful for 10 seconds, it will automatically sleep; other buttons have no wake-up function.
3. Charging instructions:
When the handle is turned off, LED1-LED4 flashes slowly when charging, and the LED is off;
Battery low voltage alarm: The current channel indicator flashes (flashing); the current channel indicator flashes (slow flash) when charging, and the current indicator is always on when fully charged;
In pairing, when charging back or low power, pairing, back to LED indication is preferred.
4. Automatic sleep:
The host screen is closed and the handle is automatically hibernated; in Bluetooth mode, press the Home button for 5 seconds to disconnect from the host.
Automatically sleeps without any button presses within 5 minutes (including the sensor does not move).
5. Low voltage alarm:
When the lithium battery voltage is lower than 3.55V±0.1V, the current channel light flashes promptly that the voltage is low; when the lithium battery voltage is lower than 3.45V±0.1V, it automatically sleeps.
6. Turbo and AutoTurbo features:
1, in any mode
Press the (first time) A/B/X/Y/L1/L2/R1/R2 and Turbo keys to set the Turbo function (automatically burst when the button is pressed);
Pressing TURBO again (the second time) realizes the Auto Turbo function (automatic burst when the button is released);
Again (third time) press the A/B/X/Y/L1/L2/R1/R2 and Turbo keys separately to clear the Turbo function of the single button;
Press and hold “—” and the DOWN button at the same time to clear the Turbo function of all buttons.
2, TURBO speed adjustment (there is three speeds can be adjusted, the default is second gear)
Adjustment method: long press 5S TURBO button and then put the right 3D up to the maximum speed will increase by one file
Long press the 5S TURBO button and then hold the right 3D down to the maximum speed.
The third speed is: continuous bursts of 5 times per second (1st gear); continuous bursts of 12 times per second (2 files); continuous bursts of 20 times per second (3 files);
Note: The Turbo function has no memory and no LED indication; the screen capture buttons in PC and Android mode have no function.
7. USB function:
Operation mode: Insert SWITCH host automatically recognizes as SWITCH, insert PC into standard XINPPUT mode;
USB LED indicator: SWITCH: Assigned by the host; XINPUT: LED1, LED4 is on.
PC-USB upgrade: Press the L3 and then plug in the PC-USB to enter the upgrade state. Open the upgrade software and follow the steps to upgrade the controller software.
8. Technical parameters:
Shutdown current is less than 15uA,
Pairing current 30~60mA,
Working current (NFC off) 20~30mA, NFC open 80~90mA;
The charging current is 150~200mA.
