JACK GD is produced and elaborated.It is a very durable and practical 1.5 inch/DN40 round flange ball valve. Exquisite workmanship, reliable sealing, use guarantee! The main material is aluminium alloy. Brief outline size: valve body length 81 mm, with a total length of 85 mm belt. The outer diameter of round flange is 135mm, the thickness is 13mm, the diagonal installation hole distance of flange is 110mm, the parallel hole distance is 78mm, the hole diameter is 13mm, and the circulation hole diameter is 45mm. The length of the handle is 195mm.Installation hole square groove 18mm*18mm.2.3KG

Brief physical pictures:

Our shopkeeper is a professional computer tanker machine repair, from a family of petroleum machinery accessories.Proficient in electronic circuit control principle and mechanical work of tanker and other machines, rich field experienceDeeply understand the actual needs and use of friends! Recommend this high quality baby specially! Easy for friends to use! When you encounter difficulties and puzzles in installation and use, or at gas stations, you can directly contact the tanker, and there will be solutions and assistance!

Usage and precautions: Before use, be sure to keep the direction of rotation in order to avoid inconvenience caused by misalignment and sprain the handle. If the tanker is parked for a long time or not used in winter, please discharge the liquid in the tank in advance to avoid freezing and cracking of the valve body. Suitable for oil trucks, oil depots, etc.

When installing the screw on the valve body, the correct method is that all corners of the flange should be uniformly stressed, and the stress on one side should not be too tight, so as to avoid inappropriate manual installation method, leading to the scrap of the valve body.

Using medium gasoline, diesel oil, kerosene, etc., nominal pressure 0.4 MPa shell test pressure 0.6 MPa seal test pressure 0.45 MPa

Aluminum alloy main case, PTFE surface seal, oil-resistant rubber stem seal, cast steel handle, chrome plated steel stem 45. Use temperatures - 30 to 55 degrees Celsius.

It can be guaranteed and maintained for life, but due to the slight profit, the freight is paid by the buyer, please forgive me!

Special attention: because the products are sold at par price, the profit is thin! Please contact me by telephone or Internet before you take a picture of your baby. It's better to wait until you have consulted the express delivery or the exact price of logistics before making payment. Avoid errors! Thank you for your support!
