7-дюймовый 1920*1200 IP Camera Tester 4K 1080P IPC CCTV Monitor Video Audio POE Test Touch Screen HDMl Discovery 8GB 9800PLUS Monitor On

7-дюймовый 1920*1200 IP Camera Tester 4K 1080P IPC CCTV Monitor Video Audio POE Test Touch Screen HDMl Discovery 8GB 9800PLUS On

IPC9800C Plus: for IP+analog camera test+RJ45 cable TDR test+HDMI out+cable tracer

IPC9800ADHC Plus: for IP+analog+AHD+HD-TVI+CVIcamera test+RJ45 cable TDR test+HDMIin/out

IPC9800ADHSC Plus: for IP+analog+AHD+HD-TVI+CVI+SDI camera test+RJ45 cable TDR test+HDMIin/out


IPC9800MOVTADHSC Plus: for IP+analog+AHD+HD-TVI+CVI+SDIcamera test+Digital Multimeter+Optical power meter+ Visual fault locator+ TDR cable test + Video level meter+cable tracer+ RJ45 cable TDR test+HDMI in/out

Main fuction:

(1)  7 inch IPS touch screen, 1280*800 resolution ,POE, DC 12V power voltage test, 1080P HDMI input,

(2) IP camera test:  4K H.265 H.264 video display via mainstream.

      * IPC test /IPC viewer /Rapid Video/RTSP /ONVIF, Rapid Video   can create testing report;

      * Hik test tool: pressing just one key to activate hikvision camera , Image test, can modify the user name, password and IP parameters;

      * Dahua camera test:  modify the user name, password and IP parameters ;

 (3) TesterPlay:Tester, android version mobile phone, PC display at the same time.

(4) HD Coxial Camera Test:(optional)

* AHD camera test :5MP AHD camera test,2592x1944P 12.5/20FPS, UTC control/ call OSD menu

* TVI camera test:  8MP TVI camera test,3840x2160P 12.5FPS, UTC control/ call OSD menu

* CVI camera test : 8MP CVI camera test, 3840x2160P 12.5/20FPS,UTC control d call OSD menu

* HD SDI/EX-SDI camera test :1080P 50/60 FPS

(5) Digital Multimeter(optional):DC and AC voltage measurement, Resistance measurement, Continuity test, Diode measurements, Capacitance measurement

(6) Optical power meter(optional): Wavelength:1625,1550nm,1490nm,1310nm,1300nm,850nm, measurement range , -70 ～+10dBm, for optical power testing and Fiber link loss relative measurement

(7) Visual fault locator(optional): 10mW visual fault locator with 650nm wavelength can emit red laser sources to test multi-mode and single mode fiber's bending and breakage, test range 10KM

(8) TDR cable test(optional): BNC cable, network cable, telephone cable, RVV cable and elevator cable, cat 5/6 cable's length and short circuit. measurement range 1.2KM

(9)Language support: English, Chinese, Korean, Russian, Italian , Polish ,Spanish, French or Japanese;

Main Features:

1)     New 7 inch IPS touch screen cctv tester,1280*800 resolution.

2)     New- H.264 and H .265 ,4K video display via mainstream

3)     New- 8MP TVI test,3840x2160P 12.5FPS,4xzoom ,video record and playback ,coaxial PTZ control and call camera OSD menu(optional)

4)     5MP AHD test,2592x1944P 12.5/20FPS,4xzoom ,video record and playback ,coaxial PTZ control and call camera OSD menu(optional)

5)     8MP CVI test, 3840x2160P 12.5/20FPS, 4xzoom ,video record and playback ,coaxial PTZ control and call camera OSD menu(optional)

6)      HD SDI/EX-SDI camera test ,support 1080P 50/60 FPS(optional)

7)      IP & CVBS camera test, PTZ controller

8)      New- Rapid video, just by one key to detect all network cameras and auto display

9)      Rapid ONVIF, auto log in and display image from the camera, activate Hikvision camera, and also can create testing report

10)     New- IP and analog testing at the same time , converter test from analog to digital with dual test window IP & CVBS

11)     New- Screen management, change function's icons order, create new directory

12)     New- Shortcut button, drop-down menu , can select PoE power ,IP setting, WLAN switch, HDMI IN functions etc in any interface

13)     Improvement cable tester, UTP cable, telephone cable etc order and connectivity test, can save testing report, if special number, need customized

14)     New- RJ45 cable TDR test, test cable pair status, length, attenuation, reflectivity, impedance, skew etc

15)     TesterPlay(screen projection): tester, android version mobile phone and PC display at the same time

16)     New- Screen lock, password lock and pattern lock are optional

17)     New- HDMI signal input,720×480p /720×576p /1280×720p /1920×1080p /1024×768p/1280×1024p /1280×900p /1440×900p display image ,record and snapshot

18)     HDMI output ,support 1080P

19)     New- CVBS loop test , the tester send and receive color bar generator signal ,to check BNC cable

20)     New- Traffic monitoring of the tester "LAN port", display network port or WIFI connection real-time upload and download speeds and other network parameters

21)     New- Customers self update software ,you can install apps with android version ,such as Skype, wechat etc

22)     ONVIF camera test, support 2592*1520, Network PTZ controller (ONVIF)

23)     Built in Wi-Fi ,display image from the wireless camera , create WIFI hotspot

24)     New- 4K video files and MKV/MP4 media files play

25)     PoE DC48V power output, Max power 24W,12V /2A power output/5V 2A power output, as a power bank

26)     New- Quick office, quick office app ( support excel ,word ,ppt format ) doc. editable

27)     8GB SD card including

28)     IP discovery, it can auto-scan the whole network segment IP, and auto-modify tester's IP address

29)     Display its genuine resolution of the IP camera images

30)     Supports more than 30 protocols such as PELCO-P, PELCO-D, and SAMSUNG

31)     Enhanced Color bar generator, PAL/NTSC multi-system color bar video generator

32)     POE voltage measurement, PING test ,IP address scan, port flashing etc

33)     Audio in /out , support record and save the audio/LED lamp, calculators, music players and other application tools

34)     7.4 V /5000mAh Lithium Ion Polymer Battery, after 5~6 hours charging , working time lasts 10 hours
