Overview:

MKS-SGEN_L is a 3D printer ARM motherboard by Makerbase. It uses a 32-bit Cortex-M3 LPC 1768 processor , running frequency is up to 100 MHz. It can be compatible with Smoothieware and Marlin 2.0 firmware. It support in-line drivers and external drivers. And the in-line driver is compatible with various modes (uart, spi, etc.). It is compatible with multiple LCD screens and MKS series touch screens. It is a versatile and cost-effective motherboard.

Features: Adopt 32-bit Cortex-M3 LPC 1768 chip, 100MHZ frequency, strong computing power, performance greatly improved. It has both in-line drive port and external drive port, which is more expandable and selective. Compatible with a variety of drivers and special modes (TMC2208 UART mode, TMC2130 SPI mode, etc.), dedicated port reservation, wiring settings are more convenient. Support multiple open-source firmwares, including Smoothieware and Marlin V2.0. Use high-quality circuit boards, and the corresponding pins of each interface are marked with silk screen for easier identification and modification. Using a dedicated power chip, support 12V-24V power input. Compatible with MKS LCD12864, MKS MINI12864 and other control boards developed by the Makerbase. Compatible with all of MKS TFT touch screens. Size: Wiring: Pinout: Motor Driver Setting: Step /dir Normal Mode: Uart Mode (MKS TMC2208 V2.0 / TMC2209 V2.0): SPI Mode(MKS TMC2130_SGL): Sensorless-homing function: Used sensorless-homing on mks sgen_l by set jumper cap like below (MKS TMC2209 V2.0):
