body { font-size: 75%; color: #000; font-family: Open Sans,Arial,Helvetica,sans-senif,SimSun,"宋体"; line-height: 1.3; } dl { margin: 0px; width: 480px; float: left; } dt { width: 100px; height: 15px; float: left; } dd { width: 240px; height: 15px; float: left; } dl dt { margin: 0px; line-height: 22px; color: #474747; font-size: 14px; font-family: tahoma; } #product-desc { width: 100%; height: 209px; } #description { width: 100%; height: 50%; } #details { width: 100%; height: 50%; } .ui-box-title { height: 30px; font-size: 15px; font-family: tahoma; font-weight: bold; background-color: #ddd; text-anchor: inherit; padding-top: 8px; margin: 0px; } .ui-box-body { margin: 0px; } #tbspecifics { border-right: 1px solid black; border-bottom: 1px solid black; } #tbspecifics tr { height: 30px; } #tbspecifics td { width: 100px; border-left: 1px solid black; border-top: 1px solid black; } Photoelectric in RS485 Strong mode control anti-interference and long distance transmission (1200 meters maximum).
Max controlled DVR:16 pieces;Max controlled speed dome and decoder:64 pieces
Variable speed operation can be applied to the camera's built-in tray / tilt.
You can control the zoom of the lens.
Easy to configure and execute the preset positions and tour group.
It is easy to set the left and right limitation positions and scan between them.
Start (default) the position can be set,activated and closed by the controller.
Built-in HIKVISION ...DAHUA ...HANBANG DVR control protocols?
Integrated PANASONIC PTZ camera communication protocols,pelco-p,Samsung.
Power supply DC9V Relative humidity Less than or equal to 90% RH
Always Power Adapter AC110V or 220V (Positive and negative 10%) switch to DC 9V 9V 1A Operating temperature -10 to 60 Celsius
Communication baud rate 2400/4800/9600 bits / S Address Chamber Range 1-255
Max controllable cameras 64 units PTZ cameras or decoders etc terminal Devices Built-in multi-protocol
Pelco-D Pelco-P Samsung PANASONIC
Plug Type:EU Plug,it applies to Indonesia,Germany,France,Spain,Italy and so on.
/
Plug Type:US Plug,it applies to Canada,India,Japan,Mexico,Thailand,Taiwan,the United States,the Philippines and so on.
colour:black
Material:plastic
Size:292*133mm
Package Contents:
1* tilt monitoring keyboard(with EU Plug,English manual)
/
1* tilt monitoring keyboard(with Us plug,English manual)
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
